Shaft Dia. | Bore Dia. | Total In | Total Seal | ProTech | |||
Bore Depth | Width | Part Number | |||||
12.7 | 22.6 | 7.0 | 16.0 | LSM-0127-0226-1-1 | |||
12.7 | 22.7 | 7.0 | 16.0 | LSM-0127-0227-1-1 | |||
12.7 | 26.7 | 10.0 | 10.0 | LNM-0127-0267-1-1 | |||
12.7 | 28.6 | 10.0 | 10.0 | LNM-0127-0286-1-1 | |||
13.0 | 32.0 | 15.0 | 15.0 | FNM-0130-0320-1-1 | |||
15.0 | 26.0 | 7.0 | 16.0 | LSM-0150-0260-1-1 | |||
15.0 | 29.0 | 10.0 | 10.0 | LNM-0150-0290-1-1 | |||
15.0 | 30.0 | 10.0 | 10.0 | LNM-0150-0300-1-1 | |||
15.0 | 35.0 | 10.0 | 10.0 | LNM-0150-0350-1-1 | |||
15.0 | 40.0 | 7.0 | 16.0 | LSM-0150-0400-1-1 | |||
15.8 | 28.5 | 7.0 | 16.0 | LSM-0158-0285-1-1 | |||
15.9 | 28.6 | 7.0 | 16.0 | LSM-0159-0286-1-1 | |||
16.0 | 32.0 | 10.0 | 10.0 | LNM-0160-0320-1-1 | |||
16.0 | 32.0 | 10.0 | 10.0 | LNM-0160-0320-1-5 | |||
16.0 | 32.0 | 10.0 | 10.0 | LNM-0160-0320-1-5 | |||
16.0 | 35.0 | 7.0 | 16.0 | LSM-0160-0350-1-1 | |||
17.0 | 35.0 | 10.0 | 10.0 | LNM-0170-0350-1-1 | |||
17.0 | 40.0 | 7.0 | 16.0 | LSM-0170-0400-1-1 | |||
18.0 | 35.0 | 7.0 | 16.0 | LSM-0180-0350-1-1 | |||
20.0 | 35.0 | 7.0 | 16.0 | LSM-0200-0350-1-1 | |||
20.0 | 36.0 | 7.0 | 16.0 | LSM-0200-0360-1-1 | |||
20.0 | 40.0 | 7.0 | 16.0 | LSM-0200-0400-1-1 | |||
F | 20.0 | 40.0 | 8.0 | 17.0 | FSM-0200-0400-1-1 | ||
20.0 | 40.0 | 10.0 | 10.0 | LNM-0200-0400-1-1 | |||
20.0 | 40.0 | 15.0 | 15.0 | FNM-0200-0400-1-1 | |||
20.0 | 42.0 | 7.0 | 16.0 | LSM-0200-0420-1-1 | |||
20.0 | 42.0 | 10.0 | 10.0 | LNM-0200-0420-1-1 | |||
20.0 | 45.0 | 7.0 | 16.0 | LSM-0200-0450-1-1 | |||
20.0 | 46.7 | 10.0 | 10.0 | LNM-0200-0467-1-1 | |||
20.0 | 47.0 | 7.0 | 16.0 | LSM-0200-0470-1-1 | |||
20.0 | 47.0 | 10.0 | 10.0 | LNM-0200-0470-1-1 | |||
20.0 | 52.0 | 10.0 | 10.0 | LNM-0200-0520-1-1 | |||
21.0 | 35.0 | 10.0 | 10.0 | LNM-0210-0350-1-1 | |||
22.0 | 35.0 | 7.0 | 16.0 | LSM-0220-0350-1-1 | |||
22.0 | 37.0 | 7.0 | 16.0 | LSM-0220-0370-1-1 | |||
22.0 | 40.0 | 7.0 | 16.0 | LSM-0220-0400-1-1 | |||
22.0 | 40.0 | 7.0 | 16.0 | LWM-0220-0400-1-1 | |||
22.0 | 41.0 | 8.0 | 17.0 | FSM-0220-0410-1-1 | |||
22.0 | 42.0 | 7.0 | 16.0 | LSM-0220-0420-1-1 | |||
22.0 | 42.0 | 8.0 | 17.0 | FSM-0220-0420-1-1 | |||
22.0 | 42.0 | 15.0 | 15.0 | FNM-0220-0420-1-1 | |||
24.0 | 34.0 | 7.0 | 16.0 | LSM-0240-0340-1-1 | |||
24.0 | 38.0 | 10.0 | 10.0 | LNM-0240-0380-1-1 | |||
24.0 | 40.0 | 7.0 | 16.0 | LSM-0240-0400-1-1 | |||
24.0 | 40.0 | 7.0 | 16.0 | LSM-0240-0400-1-1 | |||
24.0 | 40.0 | 10.0 | 10.0 | LNM-0240-0400-1-1 | |||
24.0 | 44.0 | 8.0 | 17.0 | FSM-0240-0440-1-1 | |||
24.0 | 45.0 | 7.0 | 16.0 | LSM-0240-0450-1-1 | |||
24.0 | 50.0 | 7.0 | 16.0 | LSM-0240-0500-1-1 | |||
24.0 | 50.8 | 7.0 | 16.0 | LSM-0240-0508-1-1 | |||
24.0 | 50.8 | 7.0 | 16.0 | LWM-0240-0508-1-1 | |||
24.5 | 52.0 | 10.0 | 10.0 | LNM-0245-0520-1-1 | |||
25.0 | 35.0 | 7.0 | 16.0 | LSM-0250-0350-1-1 | |||
25.0 | 35.0 | 10.0 | 10.0 | LNM-0250-0350-2-6 | |||
25.0 | 38.0 | 7.0 | 16.0 | LSM-0250-0380-1-1 | |||
25.0 | 39.0 | 7.0 | 16.0 | LWM-0250-0390-1-1 | |||
25.0 | 39.0 | 10.0 | 10.0 | LNM-0250-0390-1-1 | |||
25.0 | 40.0 | 7.0 | 16.0 | LSM-0250-0400-1-1 | |||
25.0 | 40.0 | 10.0 | 10.0 | LNM-0250-0400-2-6 | |||
25.0 | 40.5 | 10.0 | 10.0 | LNM-0250-0405-1-1 |
Shaft Dia. | Bore Dia. | Total In | Total Seal | ProTech | |
Bore Depth | Width | Part Number | |||
25.0 | 42.0 | 7.0 | 16.0 | LSM-0250-0420-1-1 | |
25.0 | 45.0 | 7.0 | 16.0 | LSM-0250-0450-1-1 | |
25.0 | 45.0 | 10.0 | 10.0 | LNM-0250-0450-1-1 | |
25.0 | 47.0 | 7.0 | 16.0 | LSM-0250-0470-1-1 | |
25.0 | 47.0 | 7.0 | 16.0 | LWM-0250-0470-1-1 | |
25.0 | 47.0 | 10.0 | 10.0 | LNM-0250-0470-1-1 | |
25.0 | 48.0 | 7.0 | 16.0 | LSM-0250-0480-1-1 | |
25.0 | 49.0 | 7.0 | 16.0 | LSM-0250-0490-1-1 | |
25.0 | 50.0 | 7.0 | 16.0 | LSM-0250-0500-1-1 | |
25.0 | 50.0 | 7.0 | 16.0 | LWM-0250-0500-1-1 | |
25.0 | 50.0 | 10.0 | 10.0 | LNM-0250-0500-1-1 | |
25.0 | 50.4 | 15.0 | 15.0 | FNM-0250-0504-1-1 | |
25.0 | 51.0 | 7.0 | 16.0 | LSM-0250-0510-1-1 | |
25.0 | 52.0 | 7.0 | 16.0 | LSM-0250-0520-1-1 | |
25.0 | 52.0 | 10.0 | 10.0 | LNM-0250-0520-1-1 | |
25.0 | 52.0 | 15.0 | 15.0 | FNM-0250-0520-1-1 | |
25.0 | 55.0 | 10.0 | 10.0 | LNM-0250-0550-4-1 | |
25.0 | 62.0 | 7.0 | 16.0 | LSM-0250-0620-1-1 | |
25.4 | 38.1 | 7.0 | 16.0 | LSM-0254-0381-1-1 | |
26.0 | 47.0 | 8.0 | 17.0 | FSM-0260-0470-1-1 | |
26.0 | 47.0 | 10.0 | 10.0 | LNM-0260-0470-1-1 | |
27.0 | 44.5 | 10.0 | 10.0 | LNM-0270-0445-1-1 | |
27.5 | 50.0 | 7.0 | 16.0 | LSM-0275-0500-1-1 | |
28.0 | 40.0 | 7.0 | 16.0 | LSM-0280-0400-1-1 | |
28.0 | 45.0 | 7.0 | 16.0 | LSM-0280-0450-1-1 | |
28.0 | 47.0 | 7.0 | 16.0 | LSM-0280-0470-1-1 | |
28.0 | 47.0 | 10.0 | 10.0 | LNM-0280-0470-1-1 | |
28.0 | 48.5 | 7.0 | 16.0 | LSM-0280-0485-1-1 | |
28.0 | 52.0 | 7.0 | 16.0 | LSM-0280-0520-1-1 | |
28.0 | 54.0 | 7.0 | 16.0 | LSM-0280-0540-1-1 | |
28.0 | 68.0 | 8.0 | 17.0 | FSM-0280-0680-1-1 | |
28.5 | 50.8 | 7.0 | 16.0 | LSM-0285-0508-1-1 | |
28.6 | 44.5 | 10.0 | 10.0 | LNM-0286-0445-1-1 | |
28.6 | 47.6 | 10.0 | 10.0 | LNM-0286-0476-1-1 | |
29.6 | 44.0 | 7.0 | 16.0 | LSM-0296-0440-1-1 | |
30.0 | 40.0 | 7.0 | 16.0 | LSM-0300-0400-1-1 | |
30.0 | 42.0 | 7.0 | 16.0 | LSM-0300-0420-1-1 | |
30.0 | 42.0 | 7.0 | 16.0 | LWM-0300-0420-1-1 | |
30.0 | 44.0 | 7.0 | 16.0 | LSM-0300-0440-1-1 | |
30.0 | 44.0 | 10.0 | 10.0 | LNM-0300-0440-1-1 | |
30.0 | 45.0 | 7.0 | 16.0 | LSM-0300-0450-1-1 | |
30.0 | 45.0 | 10.0 | 10.0 | LNM-0300-0450-1-1 | |
30.0 | 46.0 | 7.0 | 16.0 | LSM-0300-0460-1-1 | |
30.0 | 47.0 | 7.0 | 16.0 | LSM-0300-0470-1-1 | |
30.0 | 47.0 | 7.0 | 16.0 | LWM-0300-0470-1-1 | |
30.0 | 47.0 | 10.0 | 10.0 | LNM-0300-0470-1-1 | |
30.0 | 48.0 | 7.0 | 16.0 | LSM-0300-0480-1-1 | |
30.0 | 48.0 | 10.0 | 10.0 | LNM-0300-0480-2-6 | |
30.0 | 50.0 | 7.0 | 16.0 | LSM-0300-0500-1-1 | |
30.0 | 50.0 | 8.0 | 17.0 | FSM-0300-0500-1-1 | |
30.0 | 50.0 | 8.0 | 17.0 | FSM-0300-0500-1-1 | |
30.0 | 50.0 | 10.0 | 10.0 | LNM-0300-0500-1-1 | |
30.0 | 50.0 | 15.0 | 15.0 | FNM-0300-0500-1-1 | |
30.0 | 50.5 | 7.0 | 16.0 | LSM-0300-0505-1-1 | |
30.0 | 51.0 | 7.0 | 16.0 | LSM-0300-0510-1-1 | |
30.0 | 52.0 | 7.0 | 16.0 | LSM-0300-0520-1-1 | |
30.0 | 52.0 | 10.0 | 10.0 | LNM-0300-0520-1-1 | |
30.0 | 52.0 | 15.0 | 15.0 | FNM-0300-0520-1-1 | |
30.0 | 53.4 | 10.0 | 10.0 | LNM-0300-0534-1-1 | |
30.0 | 55.0 | 7.0 | 16.0 | LSM-0300-0550-1-1 |
Shaft Dia. | Bore Dia. | Total In | Total Seal | ProTech | |
Bore Depth | Width | Part Number | |||
30.0 | 55.0 | 7.0 | 16.0 | LWM-0300-0550-1-1 | |
30.0 | 55.0 | 10.0 | 10.0 | LNM-0300-0550-1-1 | |
30.0 | 56.0 | 7.0 | 16.0 | LSM-0300-0560-1-1 | |
30.0 | 56.0 | 10.0 | 10.0 | LNM-0300-0560-2-6 | |
30.0 | 57.0 | 10.0 | 10.0 | LNM-0300-0570-1-1 | |
30.0 | 60.0 | 7.0 | 16.0 | LSM-0300-0600-1-1 | |
30.0 | 60.0 | 10.0 | 10.0 | LNM-0300-0600-1-1 | |
30.0 | 61.9 | 7.0 | 16.0 | LSM-0300-0619-1-1 | |
30.0 | 62.0 | 7.0 | 16.0 | LSM-0300-0620-1-1 | |
30.0 | 62.0 | 10.0 | 10.0 | LNM-0300-0620-1-1 | |
30.0 | 62.0 | 15.0 | 15.0 | FNM-0300-0620-1-1 | |
30.0 | 65.0 | 10.0 | 10.0 | LNM-0300-0650-1-1 | |
30.0 | 70.0 | 15.0 | 15.0 | FNM-0300-0700-1-1 | |
31.0 | 45.8 | 7.0 | 16.0 | LSM-0310-0458-1-1 | |
31.5 | 50.0 | 7.0 | 16.0 | LSM-0315-0500-1-1 | |
31.7 | 52.0 | 7.0 | 16.0 | LSM-0317-0520-1-1 | |
31.8 | 50.8 | 7.0 | 16.0 | LSM-0318-0508-1-1 | |
32.0 | 43.0 | 7.0 | 16.0 | LSM-0320-0430-1-1 | |
32.0 | 45.0 | 7.0 | 16.0 | LSM-0320-0450-1-1 | |
32.0 | 46.0 | 10.0 | 10.0 | LNM-0320-0460-1-1 | |
32.0 | 47.0 | 7.0 | 16.0 | LSM-0320-0470-1-1 | |
32.0 | 47.0 | 10.0 | 10.0 | LNM-0320-0470-1-1 | |
32.0 | 50.0 | 7.0 | 16.0 | LSM-0320-0500-1-1 | |
32.0 | 50.0 | 10.0 | 10.0 | LNM-0320-0500-1-1 | |
32.0 | 52.0 | 7.0 | 16.0 | LSM-0320-0520-1-1 | |
32.0 | 52.0 | 10.0 | 10.0 | LNM-0320-0520-1-1 | |
32.0 | 55.0 | 7.0 | 16.0 | LWM-0320-0550-1-1 | |
32.0 | 58.0 | 7.0 | 16.0 | LSM-0320-0580-1-1 | |
32.0 | 70.0 | 7.0 | 16.0 | LSM-0320-0700-1-1 | |
32.7 | 54.0 | 10.0 | 10.0 | LNM-0327-0540-1-1 | |
33.0 | 52.0 | 8.0 | 17.0 | FSM-0330-0520-1-1 | |
33.0 | 60.0 | 8.0 | 17.0 | FSM-0330-0600-1-1 | |
34.0 | 43.0 | 7.0 | 16.0 | LSM-0340-0430-1-1 | |
34.0 | 44.0 | 7.0 | 16.0 | LSM-0340-0440-1-1 | |
34.0 | 52.0 | 7.0 | 16.0 | LSM-0340-0520-1-1 | |
34.0 | 54.0 | 7.0 | 16.0 | LSM-0340-0540-1-1 | |
34.0 | 60.0 | 7.0 | 16.0 | LSM-0340-0600-1-1 | |
34.9 | 52.4 | 10.0 | 10.0 | LNM-0349-0524-1-1 | |
35.0 | 45.0 | 7.0 | 16.0 | LWM-0350-0450-1-1 | |
35.0 | 47.0 | 7.0 | 16.0 | LSM-0350-0470-1-1 | |
35.0 | 47.0 | 7.0 | 16.0 | LWM-0350-0470-1-1 | |
35.0 | 47.0 | 10.0 | 10.0 | LNM-0350-0470-1-1 | |
35.0 | 49.0 | 10.0 | 10.0 | LNM-0350-0490-1-1 | |
35.0 | 50.0 | 7.0 | 16.0 | LSM-0350-0500-1-1 | |
35.0 | 50.0 | 10.0 | 10.0 | LNM-0350-0500-1-1 | |
35.0 | 51.0 | 7.0 | 16.0 | LSM-0350-0510-1-1 | |
35.0 | 52.0 | 7.0 | 16.0 | LSM-0350-0520-1-1 | |
35.0 | 52.0 | 7.0 | 16.0 | LWM-0350-0520-1-1 | |
35.0 | 52.0 | 10.0 | 10.0 | LNM-0350-0520-1-1 | |
35.0 | 54.0 | 7.0 | 16.0 | LSM-0350-0540-1-1 | |
35.0 | 54.0 | 10.0 | 10.0 | LNM-0350-0540-2-6 | |
35.0 | 55.0 | 7.0 | 16.0 | LSM-0350-0550-1-1 | |
35.0 | 55.0 | 8.0 | 17.0 | FSM-0350-0550-1-1 | |
35.0 | 55.0 | 10.0 | 10.0 | LNM-0350-0550-1-1 | |
35.0 | 55.0 | 15.0 | 15.0 | FNM-0350-0550-1-1 | |
35.0 | 58.0 | 7.0 | 16.0 | LSM-0350-0580-1-1 | |
35.0 | 59.0 | 8.0 | 17.0 | FSM-0350-0590-1-1 | |
35.0 | 60.0 | 7.0 | 16.0 | LSM-0350-0600-1-1 | |
35.0 | 60.0 | 10.0 | 10.0 | LNM-0350-0600-1-1 | |
35.0 | 61.0 | 7.0 | 16.0 | LSM-0350-0610-1-1 | |
35.0 | 61.0 | 7.0 | 16.0 | LSM-0350-0610-1-1 | |
35.0 | 61.0 | 8.0 | 17.0 | FSM-0350-0610-1-1 | |
35.0 | 62.0 | 7.0 | 16.0 | LSM-0350-0620-1-1 | |
35.0 | 62.0 | 8.0 | 17.0 | FSM-0350-0620-1-1 | |
35.0 | 62.0 | 10.0 | 10.0 | LNM-0350-0620-1-1 | |
35.0 | 62.9 | 10.0 | 10.0 | LNM-0350-0629-1-1 |
Shaft Dia. | Bore Dia. | Total In | Total Seal | ProTech | ||||
Bore Depth | Width | Part Number | ||||||
35.0 | 63.5 | 10.0 | 10.0 | LNM-0350-0635-1-1 | ||||
35.0 | 64.0 | 10.0 | 10.0 | LNM-0350-0640-1-1 | ||||
35.0 | 65.0 | 7.0 | 16.0 | LSM-0350-0650-1-1 | ||||
35.0 | 68.0 | 7.0 | 16.0 | LSM-0350-0680-1-1 | ||||
35.0 | 71.0 | 10.0 | 10.0 | LNM-0350-0710-1-1 | ||||
35.0 | 72.0 | 7.0 | 16.0 | LSM-0350-0720-1-1 | ||||
35.5 | 52.7 | 7.0 | 16.0 | LSM-0355-0527-1-1 | ||||
36.0 | 50.0 | 7.0 | 16.0 | LSM-0360-0500-1-1 | ||||
36.0 | 52.0 | 7.0 | 16.0 | LSM-0360-0520-1-1 | ||||
36.0 | 55.0 | 8.0 | 17.0 | FSM-0360-0550-1-1 | ||||
36.0 | 61.4 | 15.0 | 15.0 | FNM-0360-0614-1-1 | ||||
36.0 | 62.0 | 7.0 | 16.0 | LSM-0360-0620-1-1 | ||||
36.0 | 76.0 | 10.0 | 10.0 | LNM-0360-0760-1-1 | ||||
36.5 | 55.0 | 7.0 | 16.0 | LSM-0365-0550-1-1 | ||||
36.5 | 57.0 | 15.0 | 15.0 | FNM-0365-0570-1-1 | ||||
36.5 | 57.6 | 7.0 | 16.0 | LSM-0365-0576-1-1 | ||||
36.8 | 67.0 | 7.0 | 16.0 | LSM-0368-0670-1-1 | ||||
37.0 | 63.0 | 8.0 | 17.0 | FSM-0370-0630-1-1 | ||||
37.9 | 57.9 | 7.0 | 16.0 | LSM-0379-0579-1-1 | ||||
38.0 | 48.0 | 7.0 | 16.0 | LSM-0380-0480-1-1 | ||||
38.0 | 52.0 | 7.0 | 16.0 | LSM-0380-0520-1-1 | ||||
38.0 | 54.0 | 7.0 | 16.0 | LSM-0380-0540-1-1 | ||||
38.0 | 55.0 | 7.0 | 16.0 | LSM-0380-0550-1-1 | ||||
38.0 | 55.0 | 10.0 | 10.0 | LNM-0380-0550-1-1 | ||||
38.0 | 56.0 | 7.0 | 16.0 | LSM-0380-0560-1-1 | ||||
38.0 | 56.0 | 10.0 | 10.0 | LNM-0380-0560-1-5 | ||||
38.0 | 57.0 | 7.0 | 16.0 | LSM-0380-0570-1-1 | ||||
38.0 | 57.1 | 7.0 | 16.0 | LSM-0380-0571-1-1 | F | |||
38.0 | 57.1 | 10.0 | 10.0 | LNM-0380-0571-1-1 | ||||
38.0 | 58.0 | 15.0 | 15.0 | FNM-0380-0580-1-1 | ||||
38.0 | 62.0 | 7.0 | 16.0 | LSM-0380-0620-1-1 | ||||
38.0 | 62.0 | 10.0 | 10.0 | LNM-0380-0620-1-1 | ||||
38.0 | 62.0 | 15.0 | 15.0 | FNM-0380-0620-1-1 | ||||
38.0 | 64.0 | 7.0 | 16.0 | LSM-0380-0640-1-1 | ||||
38.0 | 65.0 | 8.0 | 17.0 | FSM-0380-0650-1-1 | ||||
38.0 | 69.0 | 7.0 | 16.0 | LSM-0380-0690-1-1 | ||||
38.0 | 70.0 | 7.0 | 16.0 | LSM-0380-0700-1-1 | ||||
38.0 | 72.0 | 10.0 | 10.0 | LNM-0380-0720-1-1 | ||||
38.0 | 72.2 | 7.0 | 16.0 | LSM-0380-0722-1-1 | ||||
38.1 | 57.2 | 7.0 | 16.0 | LSM-0381-0572-1-1 | ||||
39.0 | 70.0 | 7.0 | 16.0 | LSM-0390-0700-1-1 | ||||
40.0 | 52.0 | 7.0 | 16.0 | LSM-0400-0520-1-1 | ||||
40.0 | 52.0 | 7.0 | 16.0 | LWM-0400-0520-1-1 | ||||
40.0 | 54.0 | 10.0 | 10.0 | LNM-0400-0540-1-1 | ||||
40.0 | 55.0 | 7.0 | 16.0 | LSM-0400-0550-1-1 | ||||
40.0 | 55.0 | 10.0 | 10.0 | LNM-0400-0550-1-1 | ||||
40.0 | 56.0 | 7.0 | 16.0 | LSM-0400-0560-1-1 | ||||
40.0 | 56.0 | 10.0 | 10.0 | LNM-0400-0560-5-1 | ||||
40.0 | 58.0 | 7.0 | 16.0 | LSM-0400-0580-1-1 | ||||
40.0 | 58.0 | 10.0 | 10.0 | LNM-0400-0580-1-1 | ||||
40.0 | 59.0 | 7.0 | 16.0 | LSM-0400-0590-1-1 | ||||
40.0 | 60.0 | 7.0 | 16.0 | LSM-0400-0600-1-1 | ||||
40.0 | 60.0 | 8.0 | 17.0 | FSM-0400-0600-1-1 | ||||
40.0 | 60.0 | 10.0 | 10.0 | LNM-0400-0600-1-1 | ||||
40.0 | 60.0 | 15.0 | 15.0 | FNM-0400-0600-1-1 | ||||
40.0 | 62.0 | 7.0 | 16.0 | LSM-0400-0620-1-1 | ||||
40.0 | 62.0 | 10.0 | 10.0 | LNM-0400-0620-1-1 | ||||
40.0 | 63.5 | 7.0 | 16.0 | LSM-0400-0635-1-1 | ||||
40.0 | 65.0 | 7.0 | 16.0 | LSM-0400-0650-1-1 | ||||
40.0 | 65.0 | 10.0 | 10.0 | LNM-0400-0650-1-1 | ||||
40.0 | 66.0 | 7.0 | 16.0 | LSM-0400-0660-1-1 | ||||
40.0 | 70.0 | 7.0 | 16.0 | LSM-0400-0700-1-1 | ||||
40.0 | 70.0 | 8.0 | 17.0 | FSM-0400-0700-1-1 | ||||
40.0 | 70.0 | 10.0 | 10.0 | LNM-0400-0700-1-1 | ||||
40.0 | 72.0 | 7.0 | 16.0 | LWM-0400-0720-1-1 | ||||
40.0 | 78.0 | 10.0 | 10.0 | LNM-0400-0780-1-1 | ||||
Shaft Dia. | Bore Dia. | Total In | Total Seal | ProTech | |||
Bore Depth | Width | Part Number | |||||
40.0 | 80.0 | 7.0 | 16.0 | LSM-0400-0800-1-1 | |||
40.0 | 80.0 | 10.0 | 10.0 | LNM-0400-0800-1-1 | |||
41.0 | 60.0 | 15.0 | 15.0 | FNM-0410-0600-1-1 | |||
41.0 | 66.0 | 8.0 | 17.0 | LWM-0410-0660-1-1 | |||
41.3 | 63.5 | 10.0 | 10.0 | LNM-0413-0635-1-1 | |||
42.0 | 55.0 | 8.0 | 17.0 | LSM-0420-0550-1-1 | |||
42.0 | 58.0 | 8.0 | 17.0 | LSM-0420-0580-1-1 | |||
42.0 | 60.0 | 8.0 | 17.0 | LSM-0420-0600-1-1 | |||
42.0 | 60.0 | 10.0 | 10.0 | LNM-0420-0600-1-1 | |||
42.0 | 62.0 | 8.0 | 17.0 | LSM-0420-0620-1-1 | |||
42.0 | 62.0 | 8.0 | 17.0 | LWM-0420-0620-1-1 | |||
42.0 | 62.0 | 10.0 | 10.0 | LNM-0420-0620-1-1 | |||
42.0 | 68.0 | 8.0 | 17.0 | LSM-0420-0680-1-1 | |||
42.0 | 72.0 | 8.0 | 17.0 | LSM-0420-0720-1-1 | |||
42.0 | 72.0 | 10.0 | 10.0 | LNM-0420-0720-1-1 | |||
42.0 | 82.0 | 8.0 | 17.0 | LSM-0420-0820-1-1 | |||
42.5 | 68.7 | 8.0 | 17.0 | LSM-0425-0687-1-1 | |||
43.0 | 57.0 | 10.0 | 10.0 | LNM-0430-0570-1-1 | |||
43.0 | 60.0 | 8.0 | 17.0 | LSM-0430-0600-1-1 | |||
43.0 | 60.0 | 10.0 | 10.0 | LNM-0430-0600-1-5 | |||
43.0 | 62.0 | 8.0 | 17.0 | FSM-0430-0620-1-1 | |||
43.0 | 62.0 | 8.0 | 17.0 | LSM-0430-0620-1-1 | |||
43.0 | 62.0 | 10.0 | 10.0 | LNM-0430-0620-1-1 | |||
43.0 | 68.0 | 8.0 | 17.0 | FSM-0430-0680-1-1 | |||
43.0 | 69.9 | 8.0 | 17.0 | LSM-0430-0699-1-1 | |||
43.0 | 69.9 | 10.0 | 10.0 | LNM-0430-0699-1-1 | |||
43.0 | 76.5 | 8.0 | 17.0 | LSM-0430-0765-1-1 | |||
F | 43.0 | 76.5 | 10.0 | 10.0 | LNM-0430-0765-1-1 | ||
43.5 | 71.0 | 8.0 | 17.0 | LSM-0435-0710-1-1 | |||
44.0 | 58.0 | 8.0 | 17.0 | LWM-0440-0580-5-3 | |||
44.0 | 60.0 | 10.0 | 10.0 | LNM-0440-0600-1-1 | |||
44.0 | 62.0 | 10.0 | 10.0 | LNM-0440-0620-1-1 | |||
44.0 | 64.0 | 15.0 | 15.0 | FNM-0440-0640-1-1 | |||
44.0 | 65.0 | 10.0 | 10.0 | LNM-0440-0650-1-1 | |||
44.0 | 75.0 | 8.0 | 17.0 | LSM-0440-0750-1-1 | |||
44.3 | 60.2 | 10.0 | 10.0 | LNM-0443-0602-1-1 | |||
44.4 | 70.0 | 15.0 | 15.0 | FNM-0444-0700-1-1 | |||
44.4 | 73.0 | 8.0 | 17.0 | LSM-0444-0730-1-1 | |||
44.5 | 62.0 | 10.0 | 10.0 | LNM-0445-0620-1-1 | |||
44.5 | 63.5 | 8.0 | 17.0 | LSM-0445-0635-1-1 | |||
44.5 | 66.7 | 8.0 | 17.0 | LSM-0445-0667-1-1 | |||
44.5 | 70.0 | 10.0 | 10.0 | LNM-0445-0700-1-1 | |||
44.9 | 60.0 | 8.0 | 17.0 | LSM-0449-0600-1-1 | |||
45.0 | 59.6 | 8.0 | 17.0 | LSM-0450-0596-1-1 | |||
45.0 | 60.0 | 8.0 | 17.0 | LSM-0450-0600-1-1 | |||
45.0 | 60.0 | 10.0 | 10.0 | LNM-0450-0600-1-1 | |||
45.0 | 61.0 | 8.0 | 17.0 | LSM-0450-0610-1-1 | |||
45.0 | 61.0 | 10.0 | 10.0 | LNM-0450-0610-1-1 | |||
45.0 | 61.3 | 10.0 | 10.0 | LNM-0450-0613-1-1 | |||
45.0 | 62.0 | 8.0 | 17.0 | LSM-0450-0620-1-1 | |||
45.0 | 62.0 | 10.0 | 10.0 | LNM-0450-0620-1-1 | |||
45.0 | 62.0 | 10.0 | 10.0 | LNM-0450-0620-2-6 | |||
45.0 | 63.0 | 8.0 | 17.0 | LSM-0450-0630-1-1 | |||
45.0 | 64.0 | 10.0 | 10.0 | LNM-0450-0640-2-1 | |||
45.0 | 64.0 | 15.0 | 15.0 | FNM-0450-0640-1-1 | |||
45.0 | 65.0 | 8.0 | 17.0 | FSM-0450-0650-1-1 | |||
45.0 | 65.0 | 8.0 | 17.0 | LSM-0450-0650-1-1 | |||
45.0 | 65.0 | 8.0 | 17.0 | LWM-0450-0650-1-1 | |||
45.0 | 65.0 | 10.0 | 10.0 | LNM-0450-0650-1-1 | |||
45.0 | 65.0 | 10.0 | 10.0 | LNM-0450-0650-1-5 | |||
45.0 | 67.0 | 8.0 | 17.0 | LSM-0450-0670-1-1 | |||
45.0 | 68.0 | 8.0 | 17.0 | LSM-0450-0680-1-1 | |||
45.0 | 68.0 | 10.0 | 10.0 | LNM-0450-0680-1-1 | |||
45.0 | 69.0 | 8.0 | 17.0 | LSM-0450-0690-1-1 | |||
45.0 | 70.0 | 8.0 | 17.0 | FSM-0450-0700-1-1 | |||
45.0 | 70.0 | 8.0 | 17.0 | LSM-0450-0700-1-1 |
Shaft Dia. | Bore Dia. | Total In | Total Seal | ProTech | |
Bore Depth | Width | Part Number | |||
45.0 | 70.0 | 10.0 | 10.0 | LNM-0450-0700-1-1 | |
45.0 | 70.0 | 15.0 | 15.0 | FNM-0450-0700-1-1 | |
45.0 | 70.4 | 8.0 | 17.0 | FSM-0450-0704-1-1 | |
45.0 | 71.0 | 8.0 | 17.0 | LSM-0450-0710-1-1 | |
45.0 | 71.0 | 10.0 | 10.0 | LNM-0450-0710-1-1 | |
45.0 | 72.0 | 8.0 | 17.0 | LSM-0450-0720-1-1 | |
45.0 | 72.0 | 10.0 | 10.0 | LNM-0450-0720-1-1 | |
45.0 | 73.0 | 8.0 | 17.0 | LSM-0450-0730-1-1 | |
45.0 | 75.0 | 10.0 | 10.0 | LNM-0450-0750-1-1 | |
45.0 | 78.0 | 10.0 | 10.0 | LNM-0450-0780-1-1 | |
45.0 | 80.0 | 8.0 | 17.0 | LSM-0450-0800-1-1 | |
45.0 | 80.0 | 10.0 | 10.0 | LNM-0450-0800-1-1 | |
45.0 | 85.0 | 8.0 | 17.0 | LSM-0450-0850-1-1 | |
46.0 | 64.0 | 10.0 | 10.0 | LNM-0460-0640-1-1 | |
46.0 | 72.0 | 8.0 | 17.0 | LSM-0460-0720-1-6 | |
47.0 | 65.0 | 8.0 | 17.0 | LSM-0470-0650-1-1 | |
47.6 | 65.0 | 10.0 | 10.0 | LNM-0476-0650-1-1 | |
47.6 | 75.0 | 8.0 | 17.0 | LSM-0476-0750-1-1 | |
47.7 | 78.0 | 8.0 | 17.0 | LSM-0477-0780-1-1 | |
48.0 | 62.0 | 8.0 | 17.0 | LSM-0480-0620-1-1 | |
48.0 | 64.0 | 8.0 | 17.0 | LSM-0480-0640-1-1 | |
48.0 | 68.0 | 8.0 | 17.0 | FSM-0480-0680-1-1 | |
48.0 | 68.0 | 8.0 | 17.0 | LSM-0480-0680-1-1 | |
48.0 | 68.0 | 10.0 | 10.0 | LNM-0480-0680-1-1 | |
48.0 | 68.7 | 8.0 | 17.0 | LSM-0480-0687-1-1 | |
48.0 | 70.0 | 8.0 | 17.0 | LSM-0480-0700-1-1 | |
48.0 | 72.0 | 8.0 | 17.0 | LSM-0480-0720-1-1 | |
48.0 | 72.0 | 10.0 | 10.0 | LNM-0480-0720-1-1 | |
48.0 | 74.0 | 8.0 | 17.0 | LSM-0480-0740-1-1 | |
48.0 | 75.0 | 8.0 | 17.0 | LSM-0480-0750-1-1 | |
49.0 | 76.0 | 8.0 | 17.0 | LSM-0490-0760-1-1 | |
49.9 | 75.3 | 8.0 | 17.0 | LSM-0499-0753-1-1 | |
50.0 | 64.0 | 10.0 | 10.0 | LNM-0500-0640-1-1 | |
50.0 | 65.0 | 8.0 | 17.0 | LSM-0500-0650-1-1 | |
50.0 | 65.0 | 10.0 | 10.0 | LNM-0500-0650-1-1 | |
50.0 | 66.0 | 8.0 | 17.0 | LSM-0500-0660-1-1 | |
50.0 | 66.0 | 10.0 | 10.0 | LNM-0500-0660-1-1 | |
50.0 | 68.0 | 8.0 | 17.0 | LSM-0500-0680-1-1 | |
50.0 | 68.0 | 10.0 | 10.0 | LNM-0500-0680-1-1 | |
50.0 | 70.0 | 8.0 | 17.0 | FSM-0500-0700-1-1 | |
50.0 | 70.0 | 8.0 | 17.0 | FSM-0500-0700-5-1 | |
50.0 | 70.0 | 8.0 | 17.0 | LSM-0500-0700-1-1 | |
50.0 | 70.0 | 10.0 | 10.0 | LNM-0500-0700-1-1 | |
50.0 | 72.0 | 8.0 | 17.0 | LSM-0500-0720-1-1 | |
50.0 | 72.0 | 8.0 | 17.0 | LWM-0500-0720-1-1 | |
50.0 | 72.0 | 10.0 | 10.0 | LNM-0500-0720-1-1 | |
50.0 | 75.0 | 8.0 | 17.0 | LSM-0500-0750-1-1 | |
50.0 | 75.0 | 10.0 | 10.0 | LNM-0500-0750-1-1 | |
50.0 | 76.0 | 8.0 | 17.0 | FSM-0500-0760-1-1 | |
50.0 | 76.0 | 8.0 | 17.0 | LSM-0500-0760-1-1 | |
50.0 | 76.0 | 10.0 | 10.0 | LNM-0500-0760-1-1 | |
50.0 | 79.5 | 10.0 | 10.0 | LNM-0500-0795-1-1 | |
50.0 | 80.0 | 8.0 | 17.0 | LSM-0500-0800-1-1 | |
50.0 | 80.0 | 10.0 | 10.0 | LNM-0500-0800-1-1 | |
50.0 | 80.0 | 15.0 | 15.0 | FNM-0500-0800-1-1 | |
50.0 | 85.0 | 8.0 | 17.0 | LSM-0500-0850-5-1 | |
50.0 | 86.0 | 8.0 | 17.0 | FSM-0500-0860-1-1 | |
50.0 | 90.0 | 8.0 | 17.0 | LSM-0500-0900-1-1 | |
50.0 | 90.0 | 10.0 | 10.0 | LNM-0500-0900-1-1 | |
50.0 | 90.0 | 10.0 | 10.0 | LNM-0500-0900-1-1 | |
50.8 | 69.9 | 10.0 | 10.0 | LNM-0508-0699-1-1 | |
50.8 | 75.0 | 8.0 | 17.0 | LSM-0508-0750-1-1 | |
50.8 | 76.2 | 8.0 | 17.0 | LSM-0508-0762-1-1 | |
51.0 | 76.2 | 8.0 | 17.0 | LSM-0510-0762-1-1 | |
51.5 | 66.7 | 10.0 | 10.0 | LNM-0515-0667-1-1 | |
52.0 | 68.0 | 8.0 | 17.0 | LSM-0520-0680-1-1 |
Shaft Dia. | Bore Dia. | Total In | Total Seal | ProTech | |
Bore Depth | Width | Part Number | |||
52.0 | 68.0 | 10.0 | 10.0 | LNM-0520-0680-1-1 | |
52.0 | 72.0 | 8.0 | 17.0 | LSM-0520-0720-1-1 | |
52.0 | 72.0 | 10.0 | 10.0 | LNM-0520-0720-1-1 | |
52.4 | 76.2 | 10.0 | 10.0 | LNM-0524-0762-1-1 | |
54.0 | 68.1 | 10.0 | 10.0 | LNM-0540-0681-1-1 | |
54.0 | 72.0 | 8.0 | 17.0 | LSM-0540-0720-1-1 | |
54.0 | 73.0 | 8.0 | 17.0 | LSM-0540-0730-1-1 | |
54.0 | 73.0 | 10.0 | 10.0 | LNM-0540-0730-1-1 | |
54.0 | 78.0 | 8.0 | 17.0 | LWM-0540-0780-1-1 | |
54.0 | 79.4 | 8.0 | 17.0 | LSM-0540-0794-1-1 | |
54.0 | 90.0 | 8.0 | 17.0 | LSM-0540-0900-1-1 | |
55.0 | 68.0 | 8.0 | 17.0 | LSM-0550-0680-5-1 | |
55.0 | 70.0 | 8.0 | 17.0 | LSM-0550-0700-1-1 | |
55.0 | 70.0 | 8.0 | 17.0 | LSM-0550-0700-5-1 | |
55.0 | 70.0 | 8.0 | 17.0 | LWM-0550-0700-1-1 | |
55.0 | 70.0 | 10.0 | 10.0 | LNM-0550-0700-1-1 | |
55.0 | 70.5 | 8.0 | 17.0 | LSM-0550-0705-1-1 | |
55.0 | 71.0 | 8.0 | 17.0 | LSM-0550-0710-1-1 | |
55.0 | 72.0 | 8.0 | 17.0 | LSM-0550-0720-1-1 | |
55.0 | 72.0 | 10.0 | 10.0 | LNM-0550-0720-1-1 | |
55.0 | 73.0 | 8.0 | 17.0 | LSM-0550-0730-1-1 | |
55.0 | 73.0 | 10.0 | 10.0 | LNM-0550-0730-1-1 | |
55.0 | 75.0 | 8.0 | 17.0 | LSM-0550-0750-1-1 | |
55.0 | 75.0 | 8.0 | 17.0 | LSM-0550-0750-2-6 | |
55.0 | 75.0 | 10.0 | 10.0 | LNM-0550-0750-1-1 | |
55.0 | 75.0 | 15.0 | 15.0 | FNM-0550-0750-1-1 | |
55.0 | 75.3 | 8.0 | 17.0 | FSM-0550-0753-1-1 | |
55.0 | 76.0 | 10.0 | 10.0 | LNM-0550-0760-1-1 | |
55.0 | 77.0 | 8.0 | 17.0 | LSM-0550-0770-1-1 | |
55.0 | 78.0 | 8.0 | 17.0 | LSM-0550-0780-1-1 | |
55.0 | 78.0 | 10.0 | 10.0 | LNM-0550-0780-1-1 | |
55.0 | 80.0 | 8.0 | 17.0 | FSM-0550-0800-1-1 | |
55.0 | 80.0 | 8.0 | 17.0 | LSM-0550-0800-1-1 | |
55.0 | 80.0 | 10.0 | 10.0 | LNM-0550-0800-1-1 | |
55.0 | 80.0 | 15.0 | 15.0 | FNM-0550-0800-1-1 | |
55.0 | 80.4 | 8.0 | 17.0 | FSM-0550-0804-1-1 | |
55.0 | 81.0 | 8.0 | 17.0 | LSM-0550-0810-1-1 | |
55.0 | 82.0 | 8.0 | 17.0 | LSM-0550-0820-1-1 | |
55.0 | 83.0 | 8.0 | 17.0 | LSM-0550-0830-1-1 | |
55.0 | 85.0 | 8.0 | 17.0 | FSM-0550-0850-1-1 | |
55.0 | 85.0 | 8.0 | 17.0 | LSM-0550-0850-1-1 | |
55.0 | 85.0 | 10.0 | 10.0 | LNM-0550-0850-1-1 | |
55.0 | 85.0 | 15.0 | 15.0 | FNM-0550-0850-1-1 | |
55.0 | 85.5 | 10.0 | 10.0 | LNM-0550-0855-1-1 | |
55.0 | 90.0 | 8.0 | 17.0 | FSM-0550-0900-1-1 | |
55.0 | 90.0 | 8.0 | 17.0 | FSM-0550-0900-1-1 | |
55.0 | 90.0 | 8.0 | 17.0 | LSM-0550-0900-1-1 | |
55.0 | 90.0 | 10.0 | 10.0 | LNM-0550-0900-1-1 | |
55.0 | 90.0 | 15.0 | 15.0 | FNM-0550-0900-1-1 | |
55.0 | 92.0 | 10.0 | 10.0 | LNM-0550-0920-1-3 | |
55.5 | 83.5 | 8.0 | 17.0 | LSM-0555-0835-1-1 | |
56.0 | 80.0 | 8.0 | 17.0 | FSM-0560-0800-1-1 | |
56.0 | 90.0 | 10.0 | 10.0 | LNM-0560-0900-1-1 | |
56.7 | 70.0 | 8.0 | 17.0 | LSM-0567-0700-1-1 | |
57.0 | 71.0 | 10.0 | 10.0 | LNM-0570-0710-1-1 | |
57.0 | 72.0 | 10.0 | 10.0 | LNM-0570-0720-1-1 | |
57.0 | 75.0 | 8.0 | 17.0 | LSM-0570-0750-1-1 | |
57.0 | 76.0 | 8.0 | 17.0 | FSM-0570-0760-1-1 | |
57.0 | 76.2 | 8.0 | 17.0 | LSM-0570-0762-1-1 | |
57.0 | 77.0 | 10.0 | 10.0 | LNM-0570-0770-1-1 | |
57.0 | 78.0 | 8.0 | 17.0 | LSM-0570-0780-1-1 | |
57.0 | 80.0 | 10.0 | 10.0 | LNM-0570-0800-1-1 | |
57.0 | 83.0 | 8.0 | 17.0 | LSM-0570-0830-4-1 | |
57.1 | 73.0 | 8.0 | 17.0 | LWM-0571-0730-5-1 | |
57.4 | 85.5 | 8.0 | 17.0 | LSM-0574-0855-1-1 | |
57.5 | 79.7 | 8.0 | 17.0 | LSM-0575-0797-1-1 |
Shaft Dia. | Bore Dia. | Total In | Total Seal | ProTech | ||||
Bore Depth | Width | Part Number | ||||||
57.8 | 90.0 | 8.0 | 17.0 | LSM-0578-0900-1-1 | ||||
58.0 | 76.0 | 8.0 | 17.0 | LSM-0580-0760-1-1 | ||||
58.0 | 78.0 | 8.0 | 17.0 | FSM-0580-0780-1-1 | ||||
58.0 | 80.0 | 8.0 | 17.0 | FSM-0580-0800-1-1 | ||||
58.0 | 80.0 | 8.0 | 17.0 | LSM-0580-0800-1-1 | ||||
58.0 | 80.0 | 8.0 | 17.0 | LWM-0580-0800-1-1 | ||||
58.5 | 80.0 | 8.0 | 17.0 | LSM-0585-0800-1-1 | ||||
58.7 | 80.0 | 8.0 | 17.0 | LSM-0587-0800-1-1 | ||||
58.7 | 90.0 | 8.0 | 17.0 | LSM-0587-0900-1-1 | ||||
59.0 | 80.0 | 8.0 | 17.0 | LSM-0590-0800-1-1 | ||||
59.4 | 78.5 | 10.0 | 10.0 | LNM-0594-0785-1-1 | ||||
59.5 | 75.0 | 8.0 | 17.0 | LSM-0595-0750-1-1 | ||||
59.8 | 79.8 | 8.0 | 17.0 | LSM-0598-0798-1-1 | ||||
59.8 | 79.8 | 10.0 | 10.0 | LNM-0598-0798-1-1 | ||||
60.0 | 72.0 | 8.0 | 17.0 | LSM-0600-0720-1-1 | ||||
60.0 | 74.0 | 10.0 | 10.0 | LNM-0600-0740-1-1 | ||||
60.0 | 75.0 | 8.0 | 17.0 | LSM-0600-0750-1-1 | ||||
60.0 | 75.0 | 8.0 | 17.0 | LSM-0600-0750-5-1 | ||||
60.0 | 75.0 | 10.0 | 10.0 | LNM-0600-0750-1-1 | ||||
60.0 | 75.9 | 8.0 | 17.0 | LSM-0600-0759-1-1 | ||||
60.0 | 76.0 | 8.0 | 17.0 | LSM-0600-0760-1-1 | ||||
60.0 | 78.0 | 8.0 | 17.0 | LSM-0600-0780-1-1 | ||||
60.0 | 79.0 | 10.0 | 10.0 | LNM-0600-0790-1-1 | ||||
60.0 | 80.0 | 8.0 | 17.0 | FSM-0600-0800-1-1 | ||||
60.0 | 80.0 | 8.0 | 17.0 | FSM-0600-0800-1-1 | ||||
60.0 | 80.0 | 8.0 | 17.0 | FSM-0600-0800-1-1 | ||||
60.0 | 80.0 | 8.0 | 17.0 | LSM-0600-0800-1-1 | ||||
60.0 | 80.0 | 8.0 | 17.0 | LWM-0600-0800-1-1 | F | |||
60.0 | 80.0 | 10.0 | 10.0 | LNM-0600-0800-1-1 | ||||
60.0 | 80.0 | 15.0 | 15.0 | FNM-0600-0800-1-1 | ||||
60.0 | 82.0 | 8.0 | 17.0 | FSM-0600-0820-1-1 | ||||
60.0 | 82.0 | 8.0 | 17.0 | LSM-0600-0820-1-1 | ||||
60.0 | 82.0 | 10.0 | 10.0 | LNM-0600-0820-1-1 | ||||
60.0 | 82.4 | 8.0 | 17.0 | LSM-0600-0824-1-1 | ||||
60.0 | 84.0 | 8.0 | 17.0 | LSM-0600-0840-1-1 | ||||
60.0 | 85.0 | 8.0 | 17.0 | LSM-0600-0850-1-1 | ||||
60.0 | 85.0 | 10.0 | 10.0 | LNM-0600-0850-1-1 | ||||
60.0 | 85.0 | 15.0 | 15.0 | FNM-0600-0850-1-1 | ||||
60.0 | 86.0 | 8.0 | 17.0 | FSM-0600-0860-1-1 | ||||
60.0 | 86.0 | 8.0 | 17.0 | LSM-0600-0860-1-1 | ||||
60.0 | 86.0 | 10.0 | 10.0 | LNM-0600-0860-1-1 | ||||
60.0 | 86.0 | 10.0 | 10.0 | LNM-0600-0860-5-1 | ||||
60.0 | 88.5 | 8.0 | 17.0 | LSM-0600-0885-1-1 | ||||
60.0 | 88.9 | 10.0 | 10.0 | LNM-0600-0889-1-1 | ||||
60.0 | 89.0 | 10.0 | 10.0 | LNM-0600-0890-1-1 | ||||
60.0 | 90.0 | 8.0 | 17.0 | LSM-0600-0900-1-1 | ||||
60.0 | 90.0 | 10.0 | 10.0 | LNM-0600-0900-1-1 | ||||
60.0 | 92.0 | 8.0 | 17.0 | LSM-0600-0920-1-1 | ||||
60.0 | 95.0 | 8.0 | 17.0 | LSM-0600-0950-1-1 | ||||
60.0 | 100.0 | 8.0 | 17.0 | FSM-0600-1000-1-1 | ||||
60.0 | 100.0 | 8.0 | 17.0 | LSM-0600-1000-1-1 | ||||
60.0 | 100.0 | 10.0 | 10.0 | LNM-0600-1000-1-1 | ||||
60.0 | 110.0 | 10.0 | 10.0 | LNM-0600-1100-1-1 | ||||
60.3 | 82.5 | 9.0 | 18.0 | LSM-0603-0825-1-1 | ||||
60.8 | 90.0 | 9.0 | 18.0 | LSM-0608-0900-1-1 | ||||
61.0 | 100.0 | 8.0 | 17.0 | FSM-0610-1000-1-1 | ||||
61.8 | 80.0 | 9.0 | 18.0 | LSM-0618-0800-1-1 | ||||
61.9 | 81.9 | 10.0 | 10.0 | LNM-0619-0819-1-1 | ||||
62.0 | 78.0 | 9.0 | 18.0 | LSM-0620-0780-1-1 | ||||
62.0 | 80.0 | 9.0 | 18.0 | LSM-0620-0800-1-1 | ||||
62.0 | 80.0 | 10.0 | 10.0 | LNM-0620-0800-1-1 | ||||
62.0 | 84.0 | 9.0 | 18.0 | LSM-0620-0840-1-1 | ||||
62.0 | 85.0 | 9.0 | 18.0 | LSM-0620-0850-1-1 | ||||
62.0 | 85.0 | 10.0 | 10.0 | LNM-0620-0850-1-1 | ||||
62.0 | 90.0 | 10.0 | 10.0 | LNM-0620-0900-1-1 | ||||
63.0 | 80.0 | 9.0 | 18.0 | LSM-0630-0800-1-1 | ||||
Shaft Dia. | Bore Dia. | Total In | Total Seal | ProTech | |||
Bore Depth | Width | Part Number | |||||
63.0 | 80.0 | 10.0 | 10.0 | LNM-0630-0800-1-1 | |||
63.0 | 82.0 | 8.0 | 17.0 | FSM-0630-0820-1-1 | |||
63.0 | 85.0 | 10.0 | 10.0 | LNM-0630-0850-1-1 | |||
63.0 | 85.0 | 15.0 | 15.0 | FNM-0630-0850-1-1 | |||
63.0 | 89.0 | 9.0 | 18.0 | LSM-0630-0890-1-1 | |||
63.0 | 90.0 | 9.0 | 18.0 | LSM-0630-0900-1-1 | |||
63.0 | 90.0 | 10.0 | 10.0 | LNM-0630-0900-1-1 | |||
63.4 | 90.2 | 9.0 | 18.0 | LSM-0634-0902-1-1 | |||
63.5 | 79.0 | 9.0 | 18.0 | LSM-0635-0790-1-1 | |||
63.5 | 82.0 | 9.0 | 18.0 | LSM-0635-0820-1-1 | |||
63.5 | 82.5 | 9.0 | 18.0 | LSM-0635-0825-1-1 | |||
63.5 | 88.5 | 9.0 | 18.0 | LSM-0635-0885-1-1 | |||
63.5 | 91.0 | 9.0 | 18.0 | LSM-0635-0910-1-1 | |||
63.5 | 92.0 | 9.0 | 18.0 | LSM-0635-0920-1-1 | |||
63.9 | 102.0 | 10.0 | 10.0 | LNM-0639-1020-1-1 | |||
64.0 | 90.0 | 9.0 | 18.0 | LSM-0640-0900-1-1 | |||
65.0 | 79.0 | 10.0 | 10.0 | LNM-0650-0790-1-1 | |||
65.0 | 80.0 | 9.0 | 18.0 | LSM-0650-0800-1-1 | |||
65.0 | 80.0 | 10.0 | 10.0 | LNM-0650-0800-1-1 | |||
65.0 | 82.0 | 9.0 | 18.0 | LSM-0650-0820-1-1 | |||
65.0 | 84.0 | 8.0 | 17.0 | FSM-0650-0840-1-1 | |||
65.0 | 85.0 | 8.0 | 17.0 | FSM-0650-0850-1-1 | |||
65.0 | 85.0 | 9.0 | 18.0 | LSM-0650-0850-1-1 | |||
65.0 | 85.0 | 10.0 | 10.0 | LNM-0650-0850-1-1 | |||
65.0 | 85.0 | 15.0 | 15.0 | FNM-0650-0850-1-1 | |||
65.0 | 88.0 | 9.0 | 18.0 | LSM-0650-0880-1-1 | |||
65.0 | 88.0 | 10.0 | 10.0 | LNM-0650-0880-1-1 | |||
F | 65.0 | 90.0 | 8.0 | 17.0 | FSM-0650-0900-1-1 | ||
65.0 | 90.0 | 9.0 | 18.0 | LSM-0650-0900-1-1 | |||
65.0 | 90.0 | 10.0 | 10.0 | LNM-0650-0900-1-1 | |||
65.0 | 90.0 | 10.0 | 10.0 | LNM-0650-0900-5-1 | |||
65.0 | 90.4 | 9.0 | 18.0 | LSM-0650-0904-1-1 | |||
65.0 | 91.0 | 8.0 | 17.0 | FSM-0650-0910-1-1 | |||
65.0 | 91.0 | 9.0 | 18.0 | LSM-0650-0910-1-1 | |||
65.0 | 91.0 | 9.0 | 18.0 | LWM-0650-0910-5-3 | |||
65.0 | 92.0 | 9.0 | 18.0 | LSM-0650-0920-1-1 | |||
65.0 | 92.0 | 10.0 | 10.0 | LNM-0650-0920-1-1 | |||
65.0 | 93.0 | 9.0 | 18.0 | LSM-0650-0930-1-1 | |||
65.0 | 95.0 | 8.0 | 17.0 | FSM-0650-0950-1-1 | |||
65.0 | 95.0 | 10.0 | 10.0 | LNM-0650-0950-1-1 | |||
65.0 | 100.0 | 8.0 | 17.0 | FSM-0650-1000-1-1 | |||
65.0 | 100.0 | 9.0 | 18.0 | LSM-0650-1000-1-1 | |||
65.0 | 100.0 | 10.0 | 10.0 | LNM-0650-1000-1-1 | |||
65.0 | 100.0 | 15.0 | 15.0 | FNM-0650-1000-1-1 | |||
65.0 | 103.0 | 9.0 | 18.0 | LSM-0650-1030-1-1 | |||
66.0 | 94.0 | 9.0 | 18.0 | LSM-0660-0940-1-1 | |||
66.5 | 93.0 | 9.0 | 18.0 | LSM-0665-0930-1-1 | |||
66.6 | 92.0 | 9.0 | 18.0 | LSM-0666-0920-1-1 | |||
66.6 | 92.1 | 10.0 | 10.0 | LNM-0666-0921-1-1 | |||
66.7 | 82.6 | 9.0 | 18.0 | LWM-0667-0826-5-1 | |||
66.7 | 92.0 | 9.0 | 18.0 | LSM-0667-0920-1-1 | |||
67.0 | 85.0 | 9.0 | 18.0 | LSM-0670-0850-1-1 | |||
67.0 | 110.0 | 9.0 | 18.0 | LSM-0670-1100-1-1 | |||
67.6 | 95.0 | 9.0 | 18.0 | LSM-0676-0950-1-1 | |||
68.0 | 85.0 | 9.0 | 18.0 | LSM-0680-0850-1-1 | |||
68.0 | 85.0 | 10.0 | 10.0 | LNM-0680-0850-1-1 | |||
68.0 | 88.0 | 10.0 | 10.0 | LNM-0680-0880-1-1 | |||
68.0 | 90.0 | 8.0 | 17.0 | FSM-0680-0900-1-1 | |||
68.0 | 90.0 | 8.0 | 17.0 | FSM-0680-0900-1-1 | |||
68.0 | 90.0 | 9.0 | 18.0 | LSM-0680-0900-1-1 | |||
68.0 | 90.0 | 10.0 | 10.0 | LNM-0680-0900-1-1 | |||
68.0 | 95.0 | 9.0 | 18.0 | LSM-0680-0950-1-1 | |||
68.3 | 91.0 | 9.0 | 18.0 | LSM-0683-0910-1-1 | |||
69.0 | 89.0 | 10.0 | 10.0 | LNM-0690-0890-1-1 | |||
69.2 | 89.2 | 10.0 | 10.0 | LNM-0692-0892-1-1 | |||
69.6 | 90.0 | 9.0 | 18.0 | LSM-0696-0900-1-1 |
Shaft Dia. | Bore Dia. | Total In | Total Seal | ProTech | |
Bore Depth | Width | Part Number | |||
69.9 | 90.0 | 9.0 | 18.0 | LSM-0699-0900-1-1 | |
69.9 | 98.5 | 9.0 | 18.0 | LSM-0699-0985-1-1 | |
70.0 | 85.0 | 9.0 | 18.0 | LSM-0700-0850-1-1 | |
70.0 | 85.0 | 10.0 | 10.0 | LNM-0700-0850-1-1 | |
70.0 | 86.0 | 9.0 | 18.0 | LSM-0700-0860-1-1 | |
70.0 | 90.0 | 8.0 | 17.0 | FSM-0700-0900-1-1 | |
70.0 | 90.0 | 9.0 | 18.0 | LSM-0700-0900-1-1 | |
70.0 | 90.0 | 9.0 | 18.0 | LWM-0700-0900-1-1 | |
70.0 | 90.0 | 10.0 | 10.0 | LNM-0700-0900-1-1 | |
70.0 | 90.0 | 15.0 | 15.0 | FNM-0700-0900-1-1 | |
70.0 | 92.0 | 9.0 | 18.0 | LSM-0700-0920-1-1 | |
70.0 | 92.0 | 10.0 | 10.0 | LNM-0700-0920-1-1 | |
70.0 | 95.0 | 9.0 | 18.0 | LSM-0700-0950-1-1 | |
70.0 | 95.0 | 9.0 | 18.0 | LWM-0700-0950-1-1 | |
70.0 | 95.0 | 10.0 | 10.0 | LNM-0700-0950-1-1 | |
70.0 | 96.0 | 9.0 | 18.0 | LSM-0700-0960-1-1 | |
70.0 | 96.0 | 10.0 | 10.0 | LNM-0700-0960-1-1 | |
70.0 | 100.0 | 9.0 | 18.0 | LSM-0700-1000-1-1 | |
70.0 | 100.0 | 10.0 | 10.0 | LNM-0700-1000-1-1 | |
70.0 | 103.0 | 9.0 | 18.0 | LSM-0700-1030-1-1 | |
70.0 | 105.0 | 9.0 | 18.0 | LSM-0700-1050-1-1 | |
70.0 | 108.0 | 10.0 | 10.0 | LNM-0700-1080-1-1 | |
70.0 | 110.0 | 8.0 | 17.0 | FSM-0700-1100-1-1 | |
70.0 | 110.0 | 9.0 | 18.0 | LSM-0700-1100-1-1 | |
70.0 | 110.0 | 10.0 | 10.0 | LNM-0700-1100-1-1 | |
70.5 | 90.0 | 9.0 | 18.0 | LSM-0705-0900-1-1 | |
72.0 | 95.0 | 9.0 | 18.0 | LSM-0720-0950-1-1 | |
72.0 | 95.0 | 10.0 | 10.0 | LNM-0720-0950-1-1 | |
72.0 | 98.0 | 9.0 | 18.0 | LSM-0720-0980-1-1 | |
72.0 | 100.0 | 9.0 | 18.0 | LSM-0720-1000-1-1 | |
73.0 | 95.2 | 9.0 | 18.0 | LSM-0730-0952-1-1 | |
73.0 | 98.4 | 8.0 | 17.0 | FSM-0730-0984-1-1 | |
73.0 | 99.0 | 9.0 | 18.0 | LSM-0730-0990-1-1 | |
73.0 | 101.7 | 10.0 | 10.0 | LNM-0730-1017-1-1 | |
74.0 | 110.0 | 9.0 | 18.0 | LSM-0740-1100-1-1 | |
74.6 | 95.2 | 9.0 | 18.0 | LSM-0746-0952-1-1 | |
75.0 | 90.0 | 9.0 | 18.0 | LSM-0750-0900-1-1 | |
75.0 | 90.0 | 9.0 | 18.0 | LWM-0750-0900-1-1 | |
75.0 | 90.0 | 10.0 | 10.0 | LNM-0750-0900-1-1 | |
75.0 | 95.0 | 9.0 | 18.0 | LSM-0750-0950-1-1 | |
75.0 | 95.0 | 9.0 | 18.0 | LSM-0750-0950-1-1 | |
75.0 | 95.0 | 9.0 | 18.0 | LWM-0750-0950-1-1 | |
75.0 | 95.0 | 10.0 | 10.0 | LNM-0750-0950-1-1 | |
75.0 | 97.0 | 9.0 | 18.0 | LSM-0750-0970-1-1 | |
75.0 | 100.0 | 8.0 | 17.0 | FSM-0750-1000-1-1 | |
75.0 | 100.0 | 9.0 | 18.0 | LSM-0750-1000-1-1 | |
75.0 | 100.0 | 9.0 | 18.0 | LWM-0750-1000-1-1 | |
75.0 | 100.0 | 10.0 | 10.0 | LNM-0750-1000-1-1 | |
75.0 | 100.0 | 15.0 | 15.0 | FNM-0750-1000-1-1 | |
75.0 | 101.0 | 8.0 | 17.0 | FSM-0750-1010-1-1 | |
75.0 | 101.0 | 9.0 | 18.0 | LSM-0750-1010-1-1 | |
75.0 | 105.0 | 9.0 | 18.0 | LSM-0750-1050-1-1 | |
75.0 | 105.0 | 10.0 | 10.0 | LNM-0750-1050-1-1 | |
75.0 | 106.0 | 9.0 | 18.0 | LSM-0750-1060-1-1 | |
75.0 | 108.0 | 10.0 | 10.0 | LNM-0750-1080-1-1 | |
75.0 | 109.0 | 9.0 | 18.0 | LSM-0750-1090-1-1 | |
75.0 | 110.0 | 9.0 | 18.0 | LSM-0750-1100-1-1 | |
75.0 | 110.0 | 10.0 | 10.0 | LNM-0750-1100-1-1 | |
76.0 | 100.0 | 10.0 | 10.0 | LNM-0760-1000-1-1 | |
76.2 | 107.9 | 9.0 | 18.0 | LSM-0762-1079-1-1 | |
77.0 | 95.0 | 9.0 | 18.0 | LSM-0770-0950-1-1 | |
78.0 | 98.0 | 10.0 | 10.0 | LNM-0780-0980-1-1 | |
78.0 | 100.0 | 9.0 | 18.0 | LSM-0780-1000-1-1 | |
78.0 | 100.0 | 10.0 | 10.0 | LNM-0780-1000-1-1 | |
78.0 | 110.0 | 9.0 | 18.0 | FSM-0780-1100-1-1 | |
79.0 | 100.0 | 9.0 | 18.0 | LSM-0790-1000-1-1 |
Shaft Dia. | Bore Dia. | Total In | Total Seal | ProTech | |
Bore Depth | Width | Part Number | |||
79.0 | 119.0 | 10.0 | 10.0 | LNM-0790-1190-1-1 | |
79.5 | 105.0 | 15.0 | 15.0 | FNM-0795-1050-1-1 | |
80.0 | 100.0 | 9.0 | 18.0 | LSM-0800-1000-1-1 | |
80.0 | 100.0 | 10.0 | 10.0 | LNM-0800-1000-1-1 | |
80.0 | 100.0 | 15.0 | 15.0 | FNM-0800-1000-1-1 | |
80.0 | 101.0 | 9.0 | 18.0 | LSM-0800-1010-1-1 | |
80.0 | 104.0 | 10.0 | 10.0 | LNM-0800-1040-1-1 | |
80.0 | 105.0 | 9.0 | 18.0 | LSM-0800-1050-1-1 | |
80.0 | 105.0 | 10.0 | 10.0 | LNM-0800-1050-1-1 | |
80.0 | 106.0 | 9.0 | 18.0 | FSM-0800-1060-1-1 | |
80.0 | 106.0 | 9.0 | 18.0 | LSM-0800-1060-1-1 | |
80.0 | 106.0 | 9.0 | 18.0 | LWM-0800-1060-5-3 | |
80.0 | 106.0 | 10.0 | 10.0 | LNM-0800-1060-1-1 | |
80.0 | 110.0 | 9.0 | 18.0 | FSM-0800-1100-1-1 | |
80.0 | 110.0 | 9.0 | 18.0 | LSM-0800-1100-1-1 | |
80.0 | 110.0 | 9.0 | 18.0 | LWM-0800-1100-1-1 | |
80.0 | 110.0 | 10.0 | 10.0 | LNM-0800-1100-1-1 | |
80.0 | 110.0 | 15.0 | 15.0 | FNM-0800-1100-1-1 | |
80.0 | 111.1 | 10.0 | 10.0 | LNM-0800-1111-1-1 | |
80.0 | 115.0 | 9.0 | 18.0 | LSM-0800-1150-1-1 | |
80.0 | 115.0 | 10.0 | 10.0 | LNM-0800-1150-1-1 | |
80.0 | 115.0 | 15.0 | 15.0 | FNM-0800-1150-1-1 | |
80.0 | 119.0 | 15.0 | 15.0 | FNM-0800-1190-1-1 | |
80.0 | 120.0 | 9.0 | 18.0 | FSM-0800-1200-1-1 | |
80.0 | 120.0 | 9.0 | 18.0 | LSM-0800-1200-1-1 | |
80.5 | 110.5 | 9.0 | 18.0 | LSM-0805-1105-1-1 | |
80.9 | 108.0 | 9.0 | 18.0 | LSM-0809-1080-1-1 | |
81.5 | 101.5 | 9.0 | 18.0 | LSM-0815-1015-1-1 | |
81.8 | 106.8 | 9.0 | 18.0 | LSM-0818-1068-1-1 | |
82.0 | 110.0 | 12.0 | 12.0 | LNM-0820-1100-1-1 | |
84.0 | 103.1 | 9.0 | 18.0 | FSM-0840-1031-1-1 | |
84.0 | 109.0 | 9.0 | 18.0 | LWM-0840-1090-1-1 | |
84.0 | 110.0 | 9.0 | 18.0 | LSM-0840-1100-1-1 | |
84.0 | 115.0 | 9.0 | 18.0 | LSM-0840-1150-1-1 | |
85.0 | 101.6 | 12.0 | 12.0 | LNM-0850-1016-1-1 | |
85.0 | 105.0 | 9.0 | 18.0 | LSM-0850-1050-1-1 | |
85.0 | 105.0 | 12.0 | 12.0 | LNM-0850-1050-1-1 | |
85.0 | 108.0 | 9.0 | 18.0 | LSM-0850-1080-1-1 | |
85.0 | 110.0 | 9.0 | 18.0 | FSM-0850-1100-1-1 | |
85.0 | 110.0 | 9.0 | 18.0 | LSM-0850-1100-1-1 | |
85.0 | 110.0 | 9.0 | 18.0 | LWM-0850-1100-1-1 | |
85.0 | 110.0 | 12.0 | 12.0 | LNM-0850-1100-1-1 | |
85.0 | 110.0 | 15.0 | 15.0 | FNM-0850-1100-1-1 | |
85.0 | 110.4 | 15.0 | 15.0 | FNM-0850-1104-1-1 | |
85.0 | 110.4 | 15.0 | 15.0 | FNM-0850-1104-1-1 | |
85.0 | 111.0 | 9.0 | 18.0 | FSM-0850-1110-1-1 | |
85.0 | 111.0 | 9.0 | 18.0 | LSM-0850-1110-1-1 | |
85.0 | 111.0 | 12.0 | 12.0 | LNM-0850-1110-1-1 | |
85.0 | 112.0 | 9.0 | 18.0 | LSM-0850-1120-1-1 | |
85.0 | 112.0 | 9.0 | 18.0 | LWM-0850-1120-5-1 | |
85.0 | 115.0 | 9.0 | 18.0 | LSM-0850-1150-1-1 | |
85.0 | 120.0 | 9.0 | 18.0 | LSM-0850-1200-1-1 | |
85.0 | 120.0 | 12.0 | 12.0 | LNM-0850-1200-1-1 | |
85.0 | 125.0 | 12.0 | 12.0 | LNM-0850-1250-1-1 | |
85.1 | 119.1 | 9.0 | 18.0 | LSM-0851-1191-1-1 | |
85.7 | 108.0 | 9.0 | 18.0 | LSM-0857-1080-1-1 | |
85.7 | 110.0 | 9.0 | 18.0 | LSM-0857-1100-1-1 | |
85.7 | 117.5 | 12.0 | 12.0 | LNM-0857-1175-1-1 | |
86.0 | 110.0 | 9.0 | 18.0 | LSM-0860-1100-1-1 | |
86.0 | 111.1 | 9.0 | 18.0 | LSM-0860-1111-1-1 | |
87.0 | 114.0 | 9.0 | 18.0 | LSM-0870-1140-1-1 | |
87.8 | 112.8 | 9.0 | 18.0 | LSM-0878-1128-1-1 | |
88.0 | 110.0 | 12.0 | 12.0 | LNM-0880-1100-1-1 | |
88.9 | 107.9 | 12.0 | 12.0 | LNM-0889-1079-1-1 | |
89.0 | 110.0 | 12.0 | 12.0 | LNM-0890-1100-1-1 | |
89.1 | 112.0 | 9.0 | 18.0 | LSM-0891-1120-1-1 |
Shaft Dia. | Bore Dia. | Total In | Total Seal | ProTech | ||||
Bore Depth | Width | Part Number | ||||||
90.0 | 110.0 | 9.0 | 18.0 | FSM-0900-1100-1-1 | ||||
90.0 | 110.0 | 9.0 | 18.0 | FSM-0900-1100-1-1 | ||||
90.0 | 110.0 | 9.0 | 18.0 | LSM-0900-1100-1-1 | ||||
90.0 | 110.0 | 9.0 | 18.0 | LWM-0900-1100-1-1 | ||||
90.0 | 110.0 | 12.0 | 12.0 | LNM-0900-1100-1-1 | ||||
90.0 | 110.0 | 15.0 | 15.0 | FNM-0900-1100-1-1 | ||||
90.0 | 115.0 | 9.0 | 18.0 | LSM-0900-1150-1-1 | ||||
90.0 | 115.0 | 9.0 | 18.0 | LWM-0900-1150-1-1 | ||||
90.0 | 115.0 | 12.0 | 12.0 | LNM-0900-1150-1-1 | ||||
90.0 | 115.0 | 12.0 | 12.0 | LNM-0900-1150-1-1 | ||||
90.0 | 116.0 | 9.0 | 18.0 | LSM-0900-1160-1-1 | ||||
90.0 | 116.0 | 9.0 | 18.0 | LSM-0900-1160-5-1 | ||||
90.0 | 120.0 | 9.0 | 18.0 | FSM-0900-1200-1-1 | ||||
90.0 | 120.0 | 9.0 | 18.0 | LSM-0900-1200-1-1 | ||||
90.0 | 120.0 | 12.0 | 12.0 | LNM-0900-1200-1-1 | ||||
90.0 | 120.0 | 15.0 | 15.0 | FNM-0900-1200-1-1 | ||||
90.0 | 130.0 | 9.0 | 18.0 | LSM-0900-1300-1-1 | ||||
90.5 | 115.0 | 9.0 | 18.0 | LSM-0905-1150-1-1 | ||||
92.1 | 120.7 | 12.0 | 12.0 | LNM-0921-1207-1-1 | ||||
93.0 | 115.0 | 9.0 | 18.0 | LSM-0930-1150-1-1 | ||||
94.5 | 120.0 | 12.0 | 12.0 | LNM-0945-1200-1-1 | ||||
94.5 | 120.0 | 15.0 | 15.0 | FNM-0945-1200-1-1 | ||||
95.0 | 115.0 | 9.0 | 18.0 | LSM-0950-1150-1-1 | ||||
95.0 | 115.0 | 12.0 | 12.0 | LNM-0950-1150-1-1 | ||||
95.0 | 118.0 | 9.0 | 18.0 | LSM-0950-1180-1-1 | ||||
95.0 | 120.0 | 9.0 | 18.0 | FSM-0950-1200-1-1 | ||||
95.0 | 120.0 | 9.0 | 18.0 | LSM-0950-1200-1-1 | ||||
95.0 | 120.0 | 12.0 | 12.0 | LNM-0950-1200-1-1 | F | |||
95.0 | 120.0 | 12.0 | 12.0 | LNM-0950-1200-5-1 | ||||
95.0 | 120.0 | 15.0 | 15.0 | FNM-0950-1200-1-1 | ||||
95.0 | 120.3 | 9.0 | 18.0 | LSM-0950-1203-5-1 | ||||
95.0 | 121.0 | 9.0 | 18.0 | LSM-0950-1210-1-1 | ||||
95.0 | 125.0 | 9.0 | 18.0 | LSM-0950-1250-1-1 | ||||
95.0 | 125.0 | 12.0 | 12.0 | LNM-0950-1250-1-1 | ||||
95.0 | 125.0 | 15.0 | 15.0 | FNM-0950-1250-1-1 | ||||
95.0 | 130.0 | 12.0 | 12.0 | LNM-0950-1300-1-1 | ||||
96.0 | 122.0 | 9.0 | 18.0 | LSM-0960-1220-1-1 | ||||
96.7 | 130.0 | 9.0 | 18.0 | LSM-0967-1300-1-1 | ||||
97.0 | 114.3 | 12.0 | 12.0 | LNM-0970-1143-1-1 | ||||
97.0 | 118.0 | 9.0 | 18.0 | LSM-0970-1180-1-1 | ||||
97.0 | 125.0 | 12.0 | 12.0 | LNM-0970-1250-1-1 | ||||
99.0 | 126.0 | 9.0 | 18.0 | LSM-0990-1260-1-1 | ||||
99.5 | 120.0 | 12.0 | 12.0 | LNM-0995-1200-1-1 | ||||
100.0 | 116.0 | 9.0 | 18.0 | LSM-1000-1160-1-1 | ||||
100.0 | 120.0 | 9.0 | 18.0 | FSM-1000-1200-5-1 | ||||
100.0 | 120.0 | 9.0 | 18.0 | FSM-1000-1200-5-1 | ||||
100.0 | 120.0 | 9.0 | 18.0 | LSM-1000-1200-1-1 | ||||
100.0 | 120.0 | 9.0 | 18.0 | LSM-1000-1200-5-1 | ||||
100.0 | 120.0 | 12.0 | 12.0 | LNM-1000-1200-1-1 | ||||
100.0 | 125.0 | 9.0 | 18.0 | LSM-1000-1250-1-1 | ||||
100.0 | 125.0 | 9.0 | 18.0 | LSM-1000-1250-5-1 | ||||
100.0 | 125.0 | 12.0 | 12.0 | LNM-1000-1250-1-1 | ||||
100.0 | 125.4 | 9.0 | 18.0 | LSM-1000-1254-1-1 | ||||
100.0 | 126.0 | 9.0 | 18.0 | LSM-1000-1260-1-1 | ||||
100.0 | 126.0 | 15.0 | 15.0 | FNM-1000-1260-1-1 | ||||
100.0 | 130.0 | 9.0 | 18.0 | FSM-1000-1300-1-1 | ||||
100.0 | 130.0 | 9.0 | 18.0 | FSM-1000-1300-5-1 | ||||
100.0 | 130.0 | 9.0 | 18.0 | LSM-1000-1300-1-1 | ||||
100.0 | 130.0 | 12.0 | 12.0 | LNM-1000-1300-1-1 | ||||
100.0 | 135.0 | 9.0 | 18.0 | LSM-1000-1350-1-1 | ||||
100.0 | 135.0 | 12.0 | 12.0 | LNM-1000-1350-1-1 | ||||
100.0 | 136.5 | 12.0 | 12.0 | LNM-1000-1365-1-1 | ||||
101.4 | 127.0 | 9.0 | 18.0 | LSM-1014-1270-1-1 | ||||
101.4 | 127.0 | 9.0 | 18.0 | LSM-1014-1270-5-1 | ||||
102.0 | 137.0 | 12.0 | 12.0 | LNM-1020-1370-5-1 | ||||
104.0 | 129.0 | 9.0 | 18.0 | LSM-1040-1290-5-1 | ||||
Shaft Dia. | Bore Dia. | Total In | Total Seal | ProTech | |||
Bore Depth | Width | Part Number | |||||
104.0 | 142.0 | 9.0 | 18.0 | LSM-1040-1420-6-1 | |||
105.0 | 130.0 | 9.0 | 18.0 | FSM-1050-1300-5-1 | |||
105.0 | 130.0 | 9.0 | 18.0 | LSM-1050-1300-5-1 | |||
105.0 | 130.0 | 12.0 | 12.0 | LNM-1050-1300-5-1 | |||
105.0 | 131.0 | 9.0 | 18.0 | LSM-1050-1310-5-1 | |||
105.0 | 135.0 | 9.0 | 18.0 | LSM-1050-1350-5-1 | |||
105.0 | 137.0 | 12.0 | 12.0 | LNM-1050-1370-5-1 | |||
105.0 | 140.0 | 9.0 | 18.0 | LSM-1050-1400-5-1 | |||
105.0 | 140.0 | 12.0 | 12.0 | LNM-1050-1400-5-1 | |||
105.5 | 130.0 | 9.0 | 18.0 | LSM-1055-1300-5-1 | |||
110.0 | 130.0 | 9.0 | 18.0 | LSM-1100-1300-5-1 | |||
110.0 | 130.0 | 9.0 | 18.0 | LWM-1100-1300-5-1 | |||
110.0 | 130.0 | 12.0 | 12.0 | LNM-1100-1300-5-1 | |||
110.0 | 135.0 | 9.0 | 18.0 | LSM-1100-1350-5-1 | |||
110.0 | 136.0 | 9.0 | 18.0 | LSM-1100-1360-1-1 | |||
110.0 | 136.0 | 9.0 | 18.0 | LSM-1100-1360-5-1 | |||
110.0 | 140.0 | 9.0 | 18.0 | FSM-1100-1400-5-1 | |||
110.0 | 140.0 | 9.0 | 18.0 | LSM-1100-1400-5-1 | |||
110.0 | 140.0 | 12.0 | 12.0 | LNM-1100-1400-5-1 | |||
110.0 | 141.0 | 9.0 | 18.0 | LSM-1100-1410-5-1 | |||
110.0 | 142.0 | 9.0 | 18.0 | LSM-1100-1420-6-1 | |||
110.0 | 145.0 | 12.0 | 12.0 | LNM-1100-1450-5-1 | |||
110.0 | 149.4 | 12.0 | 12.0 | LNM-1100-1494-5-1 | |||
110.0 | 150.0 | 12.0 | 12.0 | LNM-1100-1500-5-1 | |||
111.0 | 145.0 | 9.0 | 18.0 | LSM-1110-1450-5-1 | |||
114.0 | 134.0 | 9.0 | 18.0 | FSM-1140-1340-5-1 | |||
114.0 | 140.0 | 9.0 | 18.0 | FSM-1140-1400-5-1 | |||
F | 114.3 | 150.0 | 9.0 | 18.0 | LSM-1143-1500-5-1 | ||
115.0 | 140.0 | 9.0 | 18.0 | LSM-1150-1400-4-1 | |||
115.0 | 140.0 | 9.0 | 18.0 | LSM-1150-1400-5-1 | |||
115.0 | 140.0 | 12.0 | 12.0 | LNM-1150-1400-5-1 | |||
115.0 | 141.0 | 9.0 | 18.0 | LSM-1150-1410-5-1 | |||
115.0 | 145.0 | 9.0 | 18.0 | LSM-1150-1450-5-1 | |||
115.0 | 145.0 | 12.0 | 12.0 | LNM-1150-1450-5-1 | |||
115.0 | 155.0 | 9.0 | 18.0 | LSM-1150-1550-5-1 | |||
117.2 | 143.2 | 9.0 | 18.0 | LSM-1172-1432-5-1 | |||
117.5 | 146.0 | 12.0 | 12.0 | LNM-1175-1460-5-1 | |||
118.0 | 150.0 | 9.0 | 18.0 | LSM-1180-1500-5-1 | |||
118.0 | 150.0 | 12.0 | 12.0 | LNM-1180-1500-5-1 | |||
119.9 | 142.2 | 9.0 | 18.0 | LSM-1199-1422-5-1 | |||
120.0 | 140.0 | 9.0 | 18.0 | FSM-1200-1400-5-1 | |||
120.0 | 140.0 | 9.0 | 18.0 | FSM-1200-1400-5-5 | |||
120.0 | 142.0 | 9.0 | 18.0 | LSM-1200-1420-5-1 | |||
120.0 | 145.0 | 9.0 | 18.0 | LSM-1200-1450-5-1 | |||
120.0 | 146.0 | 9.0 | 18.0 | LSM-1200-1460-5-1 | |||
120.0 | 148.0 | 12.0 | 12.0 | LNM-1200-1480-5-1 | |||
120.0 | 150.0 | 9.0 | 18.0 | FSM-1200-1500-5-1 | |||
120.0 | 150.0 | 9.0 | 18.0 | LSM-1200-1500-5-1 | |||
120.0 | 150.0 | 12.0 | 12.0 | LNM-1200-1500-4-1 | |||
120.0 | 150.0 | 12.0 | 12.0 | LNM-1200-1500-5-1 | |||
120.0 | 160.0 | 9.0 | 18.0 | FSM-1200-1600-5-1 | |||
120.0 | 160.0 | 9.0 | 18.0 | LSM-1200-1600-5-1 | |||
120.0 | 180.0 | 12.0 | 12.0 | LNM-1200-1800-5-1 | |||
122.0 | 148.0 | 9.0 | 18.0 | LSM-1220-1480-5-1 |
Shaft Dia. | Bore Dia. | Total In | Total Seal | ProTech | |
Bore Depth | Width | Part Number | |||
124.0 | 150.0 | 9.0 | 18.0 | LSM-1240-1500-5-1 | |
124.0 | 160.0 | 9.0 | 18.0 | LSM-1240-1600-5-1 | |
125.0 | 150.0 | 9.0 | 18.0 | LSM-1250-1500-5-1 | |
125.0 | 150.0 | 9.0 | 18.0 | LWM-1250-1500-5-1 | |
125.0 | 150.0 | 12.0 | 12.0 | LNM-1250-1500-5-1 | |
125.0 | 151.0 | 9.0 | 18.0 | LSM-1250-1510-5-1 | |
125.0 | 155.0 | 12.0 | 12.0 | LNM-1250-1550-5-1 | |
125.4 | 152.4 | 9.0 | 18.0 | LSM-1254-1524-5-1 | |
126.0 | 160.2 | 9.0 | 18.0 | LSM-1260-1602-5-1 | |
127.0 | 150.0 | 9.0 | 18.0 | LSM-1270-1500-5-1 | |
129.0 | 152.0 | 9.0 | 18.0 | LSM-1290-1520-5-1 | |
130.0 | 150.0 | 12.0 | 12.0 | LNM-1300-1500-5-1 | |
130.0 | 155.0 | 9.0 | 18.0 | LSM-1300-1550-5-1 | |
130.0 | 155.0 | 12.0 | 12.0 | LNM-1300-1550-5-1 | |
130.0 | 156.0 | 9.0 | 18.0 | FSM-1300-1560-5-1 | |
130.0 | 156.0 | 9.0 | 18.0 | FSM-1300-1560-5-1 | |
130.0 | 156.0 | 9.0 | 18.0 | LSM-1300-1560-5-1 | |
130.0 | 156.0 | 9.0 | 18.0 | LSM-1300-1560-5-1 | |
130.0 | 156.0 | 12.0 | 12.0 | LNM-1300-1560-5-1 | |
130.0 | 160.0 | 9.0 | 18.0 | FSM-1300-1600-5-1 | |
130.0 | 160.0 | 9.0 | 18.0 | LSM-1300-1600-5-1 | |
130.0 | 160.0 | 9.0 | 18.0 | LWM-1300-1600-5-1 | |
130.0 | 160.0 | 12.0 | 12.0 | LNM-1300-1600-5-1 | |
130.0 | 170.0 | 9.0 | 18.0 | LSM-1300-1700-5-1 | |
135.0 | 165.0 | 15.0 | 15.0 | LNM-1350-1650-5-1 | |
135.0 | 170.0 | 9.0 | 18.0 | FSM-1350-1700-5-1 | |
135.0 | 170.0 | 15.0 | 15.0 | LNM-1350-1700-5-1 | |
135.0 | 175.0 | 15.0 | 15.0 | LNM-1350-1750-5-1 | |
140.0 | 170.0 | 9.0 | 18.0 | FSM-1400-1700-5-1 | |
140.0 | 170.0 | 15.0 | 15.0 | LNM-1400-1700-5-1 | |
140.0 | 180.0 | 9.0 | 18.0 | FSM-1400-1800-5-1 | |
145.0 | 170.0 | 15.0 | 15.0 | LNM-1450-1700-5-1 | |
145.0 | 180.0 | 15.0 | 15.0 | LNM-1450-1800-5-1 | |
146.0 | 184.0 | 15.0 | 15.0 | LNM-1460-1840-5-1 | |
150.0 | 180.0 | 9.0 | 18.0 | FSM-1500-1800-5-1 | |
150.0 | 180.0 | 15.0 | 15.0 | LNM-1500-1800-5-1 | |
150.0 | 182.0 | 15.0 | 15.0 | LNM-1500-1820-5-1 | |
155.0 | 180.0 | 15.0 | 15.0 | LNM-1550-1800-5-1 | |
158.8 | 190.0 | 15.0 | 15.0 | LNM-1588-1900-5-1 | |
160.0 | 190.0 | 15.0 | 15.0 | LNM-1600-1900-5-1 | |
161.2 | 187.5 | 15.0 | 15.0 | LNM-1612-1875-5-1 | |
165.0 | 200.0 | 15.0 | 15.0 | LNM-1650-2000-5-1 | |
170.0 | 200.0 | 15.0 | 15.0 | LNM-1700-2000-5-1 | |
177.8 | 216.1 | 15.0 | 15.0 | LNM-1778-2161-5-1 | |
180.0 | 220.0 | 15.0 | 15.0 | LNM-1800-2200-5-1 | |
185.0 | 210.0 | 15.0 | 15.0 | LNM-1850-2100-5-1 | |
190.0 | 220.0 | 15.0 | 15.0 | LNM-1900-2200-5-1 | |
190.0 | 225.0 | 15.0 | 15.0 | LNM-1900-2250-5-1 | |
190.5 | 220.0 | 15.0 | 15.0 | LNM-1905-2200-5-1 | |
200.0 | 230.0 | 15.0 | 15.0 | LNM-2000-2300-5-1 | |
200.0 | 240.0 | 15.0 | 15.0 | LNM-2000-2400-5-1 | |
210.0 | 240.0 | 15.0 | 15.0 | LNM-2100-2400-5-1 | |
220.0 | 250.0 | 15.0 | 15.0 | LNM-2200-2500-5-1 |
本文链接地址:ProTech™ Sizes Inch parker 密封 F
